Basic Info:
| Junction Box | IP67 Rated | Cable | PV Cable 4mm^2, 900mm |
| Cell Orientation | 60cells(6*10) | Connector | Mc4 |
| Frame | Silver/Black Anodized Aluminium Alloy | Tpt Backsheet | White/Black Backsheet |
| Glass | 3.2mm Tempered Low Iron | Transport Package | 2PCS/Carton, 30PCS/Pallet |
Technical Specification Data(STC) of Solar Panel:
| Peak Power Watts-Pmax(Wp)* | 275 | 280 | 290 | 300 | 310 | 315 |
| Maximum Power Voltage-Vmpp(V) | 31.4 | 31.7 | 32.2 | 32.7 | 33.1 | 33.3 |
| Maximum Power Current-Impp(A) | 8.76 | 8.84 | 9.01 | 9.19 | 9.37 | 9.46 |
| Open Circuit Voltage-Voc(V) | 38.4 | 38.46 | 38.9 | 39.8 | 40.2 | 40.5 |
| Short Circuit Current-Isc(A) | 9.24 | 9.42 | 9.66 | 9.77 | 9.94 | 10 |
| Module Efficiency (%) | 16.8 | 17.1 | 17.7 | 18.3 | 18.9 | 19.2 |
| Power Output Tolerance-Pmax(W) | 0~+5 | |||||
| Temperature Coefficient of Pmax | -0.39%/ºC | |||||
| Temperature Coefficient of Voc | -0.29%/ºC | |||||
| Temperature Coefficient of Isc | 0.05%/ºC | |||||
| STC | Irradiance 1000W/m2, Cell Temperature 25 , Air Mass AM1.5 | |||||


Packing & Delivery:
Solar Panel Packing Details : 30pcs per pallets or in wooden box
Delivery Details : 5-7days
